Product Summary
The Alfresco ARXE-42 brings professional-style cold storage directly beneath your built-in grill with 7.25 cubic feet of outdoor-rated refrigeration.
Its restaurant-inspired configuration combines a refrigerator compartment with an adjustable stainless steel shelf and two marinating drawers. Each drawer includes a removable NSF food pan for conveniently storing meats, vegetables, sauces and other ingredients.
A 1,000-BTU all-weather refrigeration system, commercial fan-driven evaporator and Flash Recovery System provide dependable cooling. The digital control allows temperature adjustment from 27°F to 56°F.
Fully front-breathing construction supports built-in installation without requiring rear ventilation for normal condenser airflow. Visit Coastal Appliance Co. for Alfresco outdoor-kitchen refrigeration and professional appliance guidance throughout Hawaii.
Key Features
7.25-Cubic-Foot Capacity – Provides generous refrigerated storage directly beneath an outdoor grill or countertop.
Under-Grill Installation – Designed to integrate beneath select Alfresco built-in grills and into compatible outdoor-kitchen cabinetry.
Door and Drawer Configuration – Combines a refrigerator compartment with two dedicated marinating drawers.
Removable NSF Food Pans – Marinating drawers include removable stainless steel food pans for convenient preparation, storage and cleaning.
Adjustable Stainless Steel Shelf – Organizes beverages, ingredients, sauces and prepared foods inside the door compartment.
27°F–56°F Temperature Range – Digital controls allow the cabinet temperature to be adjusted for different storage needs.
1,000-BTU Refrigeration System – All-weather cooling system delivers dependable performance in demanding outdoor environments.
Flash Recovery System – Quickly restores the selected temperature after the door or drawers have been opened.
Fan-Driven Evaporator – Commercial-style forced-air cooling circulates cold air throughout the interior.
Fully Front-Breathing Design – Allows the refrigeration system to ventilate from the front for built-in installation.
304 Stainless Steel Construction – Stainless steel inside and out provides durability and a professional appearance.
Digital Temperature Control – Lighted electronic display provides convenient access to temperature settings.
Door-Activated Interior Light – Automatically illuminates the refrigerator compartment when the door is opened.
Commercial Foam Insulation – Shot-in-place polyurethane insulation helps maintain consistent internal temperatures.
NSF Certified – Constructed and tested to applicable National Sanitation Foundation standards.
Specifications
| Specification | Details |
|---|---|
| Brand | Alfresco |
| Model | ARXE-42 |
| Product Type | Outdoor under-grill refrigerator |
| Installation Type | Built-in |
| Nominal Size | 42 inches |
| Total Capacity | 7.25 cu. ft. |
| Configuration | One refrigerator door and two marinating drawers |
| Interior Shelf | Adjustable stainless steel wire shelf |
| Marinating Pans | Two removable stainless steel NSF food pans |
| Temperature Range | 27°F–56°F |
| Factory Temperature Setting | 35°F |
| Refrigeration Output | 1,000 BTU |
| Cooling System | Commercial fan-driven fin evaporator |
| Temperature Recovery | Flash Recovery System |
| Defrost System | Automatic |
| Controls | Digital electronic control with lighted display |
| Interior Lighting | Door-activated |
| Ventilation | Fully front-breathing |
| Exterior Material | 304 stainless steel |
| Interior Material | 304 stainless steel |
| Insulation | Commercial polyurethane foam |
| Refrigerant | R-134a |
| Electrical Requirements | 115 VAC, single phase, 2.9 amps |
| Recommended Circuit | Grounded 15-amp circuit |
| Power Cord | 8-foot cord with NEMA 5-15P plug |
| Plumbing Requirements | None |
| Wi-Fi Connectivity | No |
| ENERGY STAR® Certified | No |
| ADA Compliant | No |
| Outdoor Approved | Yes |
| NSF Certified | Yes |
| Warranty | Manufacturer limited warranty; consult current warranty documentation for complete terms |
Dimensions
| Measurement | Size |
|---|---|
| Overall Width | 44 11/16" |
| Overall Height | 24 3/16" |
| Overall Depth | 26 15/16" |
| Cutout Width | 42 1/2" |
| Cutout Height | 21 3/4" |
| Cutout Depth | 23 1/4" |
| Minimum Rear Clearance | 2" |
| Drawer Extension | 17" |
| Maximum Door Opening | 175° |
Always verify final cabinet dimensions using the current Alfresco specification sheet before constructing or modifying the outdoor-kitchen enclosure.
Installation Considerations
The ARXE-42 is intended for outdoor use and built-in under-grill installation.
The appliance requires a properly grounded three-prong electrical receptacle. A GFCI-protected circuit is recommended, and an extension cord should not be used.
Although the refrigeration system is fully front-breathing, Alfresco specifies clearance behind and beneath the cabinet for installation and service access.
Install the refrigerator in a properly ventilated area away from direct sunlight, concentrated heat sources and sprinkler spray.
Allow enough space in front of the appliance for the refrigerator door and marinating drawers to open completely.
The unit must be level to support proper operation, drainage and door alignment.
